440 Angler

  • Hull Length: 3900mm

  • Length O/A: 4400mm

  • Max Beam: 2100mm

  • Gunwale height: 700mm

  • Height on trailer: 1900mm

  • Length on trailer: 5400mm

  • Bottom Thickness: 4mm

  • Side thickness: 3mm

  • Transom thickness: 4mm

  • Hull weight: 380kg

  • Tow weight: 690kg

  • Recommended HP: 40-60

  • Deadrise: 14

480 Angler

  • Hull Length: 4400mm

  • Length O/A: 4900mm

  • Max Beam: 2100mm

  • Gunwale height: 700mm

  • Height on trailer: 1900mm

  • Length on trailer: 5900mm

  • Bottom Thickness: 4mm

  • Side thickness: 3mm

  • Transom thickness: 4mm

  • Hull weight: 410kg

  • Tow weight: 720kg

  • Recommended HP: 50-60

  • Deadrise: 14

520 Angler

  • Hull Length: 4700mm

  • Length O/A: 5200mm

  • Max Beam: 2100mm

  • Gunwale height: 700mm

  • Height on trailer: 1900mm

  • Length on trailer: 6200mm

  • Bottom Thickness: 4mm

  • Side thickness: 3mm

  • Transom thickness: 4mm

  • Hull weight: 430kg

  • Tow weight: 860kg

  • Recommended HP: 60-90

  • Deadrise: 14

  • 2 front Upholstered seats on swivels and sliders.

    2 rear alloy seats

    Non feedback cable steering

    Bilge pump 1500 Gph minimum

    4 way switch panel

    Curved acrylic windscreen with opening centre section for anchorwell access

    LED navigation and riding lights

    Vibra stop engine mounting pads

    Boarding platforms

    Bow and transom rails

    3 spoke Gussi steering wheel

    Underfloor sealed compartment for floatation

    Full length side pockets

    Glove box storage

    Storage shelf behind passenger dash

    Storage boxes under front seats

    Storage locker in bow

    Bollard and fairlead with roller

    4 x Plastic rod holders

    Graphics set

  • 12V outlet

    Ski pole

    Auto winch

    Capstan winch

    Ladder

    U-Dek flooring

    Painted cabin

    Painted sides

    Vinyl wrapped cabin

    Vinyl wrapped sides

    Rocket Launcher

  • Bait board mount post and plate only

    Bait board plastic

    Bait board Marco alloy

    Clip on storage rod holders

    Extra plastic rod holders

    Rocket Launcher

    Upgrade rod holders to alloy

  • Bimini off rocket launcher

    Bimini clears

    Canopy

    Canopy side clears

    Plastic king queen seat

    Rear seat upholstery

    Road cover

  • DMW Trailer

    Spare wheel

    Spare wheel bracket

    Walk board
